FA316B Drawing Frame
Adopt high quality 4 over 4 with guide roller, pressure stick style double-curve drafting structure. The sliver quality is good and steady.
The whole set adopts entire frame iron casting spare to becomposed, powerful rigidity, good anti-seissmic capability and good stability.
Shandong Hongye Machinery Co., Ltd. is one of the leading manufacturers and suppliers of fa316b drawing frame in China, also supports 1 year warranty. If you're going to buy the newest fa316b drawing frame made in China, welcome to get pricelist from our factory. Quality products and low price are available.
Main Features
- The machine is suitbale for fiber variety, with stable quality, and high output speed.
- Adopt high quality 4 over 4 with guide roller, pressure stick style double-curve drafting structure. The sliver quality is good and steady.
- The whole set adopts entire frame iron casting spare to becomposed, powerful rigidity, good anti-seissmic capability and good stability.
- The main motor adopts the frequency converter to dominate stepless timing, electromagnetism brake, so cause the drive to promote speed stably. Turning round at an average speed, quick brake, favorable to the sliver quality.
- Adopt PLC and counting disk with flow picture composed of high performance single chip to complete the logic control and malfunction judge of the machine so the electrical equipment domination is more stable and dependable.
- Ideal photoelectricity self-ceasing unit, the photo electricity self-ceasing unitis in front of the sliver flowing machine, coiling rolloer self-ceasing unit, so the malfunction self-ceasing is more dependable.
- The automatic can changer selected by customers, can decrease the labor intensity of workers, and improve work efficiency.
- Shave the cotton device automatically, it is clean to realize timing.
Technical Parameters
|
1. Delivery number |
2 holes |
|
2. Max.output speed |
600m/min |
|
3. Total drafting multiple |
5-14times |
|
4. Drafting style |
5 over 4 with pressurebar drafting |
|
5. Feed sliver number |
6-8 pieces |
|
6. Suitable fiber length |
15-76mm |
|
7. Input can dimension |
Φ400, Φ500, Φ600, Φ800, Φ900 Φ1000×high 900 or 1,100 (1,200)mm |
|
8. Output can dimension |
Φ230, Φ350, Φ400, Φ450, Φ500×high900or1,100mm |
|
9. Mainframe OAD |
2,120×950×1,645mm |
|
10. machine weight |
2,200kg |
|
11. Main motor power |
5.5kw |
